| Model | SDR-75-12 | SDR-75-24 | SDR-75-48 |
| DC Voltage | 12v | 24v | 48V |
| Rated Current | 6.3A | 3.2A | 1.6A |
| Current range | 0~6.3A | 0~3.2A | 0~1.6A |
| Rated power | 75.6w | 76.8w | 76.8w |
| Ripple&noise | 100mVp-p | 100mVp-p | 120mVp-p |
| Voltage ADJ | 12~14V | 24~28V | 48~55V |
| Efficiency | 88.5% | 89% | 90% |
|
Over load |
When the rated output power is 110% to 150%, turn off the output voltage after working for more than 3 seconds and restart the device |
||
|
150%~170% rated output power, constant current limit and automatic recovery within 3 seconds, 3 seconds after the output voltage off, restart recovery |
|||
|
Over voltage |
14~17V | 29~33V | 58~65V |
| Protective mode; Close the output and restart to restore | |||
