MODEL |
|
S-60-5 |
S-60-12 |
S-60-24 |
S-60-36 |
S-60-48 |
|
OUTPUT |
DC Voltage |
5V |
12V |
24V |
36V |
48V |
|
Rated Current |
12A |
5.0A |
2.5A |
1.6A |
1.25A |
|
|
Current range |
0~12A |
0~5.0A |
0~2.5A |
0-1.6A |
0-1.25A |
|
|
Rated power |
60W |
60W |
60W |
59.76W |
60W |
|
|
Ripple&noise(max. |
78mVp-p |
100mVp-p |
100mVp-p |
120mVp-p |
120mVp-p |
|
|
Voltage ADJ. range |
5~7V |
12~14V |
24~28V |
36~38V |
48V~53V |
|
|
Voltage tolerance |
±2.0% |
±2.0% |
±1.0% |
±1.0% |
±1.0% |
|
|
Line regulation |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
|
Load regulation |
±1.0% |
±1.0% |
±1.0% |
±1.0% |
±1.0% |
|
|
Setup,.Rise,Time |
200ms，78ms/230VAC 200ms，85ms/115VAC(full load) |
|||||
|
Hold up time(typ) |
20ms/230VAC 45ms/115VAC(full load) |
|||||
|
INPUT |
Voltage range |
100～132VAC/185～264VAC 260～370VDC（switch on220VAC） |
||||
|
Frequency range |
50~60Hz |
|||||
|
Efficiency(Typ) |
76% |
80% |
82% |
82% |
84% |
|
|
AC current(Typ) |
1.6A/115VAC 0.8A/230VAC |
|||||
|
Inrush current (Typ) |
Cold start: 20A/115VAC 40A/230VAC |
|||||
|
Leakage current |
<1mA/240VAC |
|||||
|
PROTECTION |
Over load |
105%~150% rated output power |
||||
|
Protection type: Hiccup mode, recovers automatically after fault condition is removed |
||||||
|
Over voltage |
8~10V |
15~16.5V |
29~33V |
40~45V |
58~65V |
|
|
Protection mode ,tum off output voltage,restart to recover |
||||||
|
Environment |
Working TEMP |
-10℃~+60℃ |
||||
|
Working humidity |
20~65% RH non-condensing |
|||||
|
Storage TEMP humidity |
-10℃~+60℃，10-95%RH |
|||||
|
TEMP.coefficient |
±0.03%℃(0~50℃) |
|||||
|
Vibration |
10~500Hz，2G 10min./1cycle，60min each along X,Y,Z axes Install in accordance with IEC60068-2-6 |
|||||
|
SAFETY |
Safety regulations |
UL60950-1. CB(IEC60950-1)In line with the certification |
||||
|
Withstand voltage |
l/P-O/P:1.5KVAC I/P-FG:1.5KVA O/P-FG:0.4KVAC |
|||||
|
Insolation resistance |
I/P-O/P. I/P-FG, O/P-FG:100M Ohms/500VDC |
|||||
|
Electromagnetic compatible emission |
Compliance to EN55022(CISPR22)CLASS B.EN61000-3-2,-3. |
|||||
|
EMC immunity requirements |
Compliance to EN61000-4-2,3,4.5,6,8,11. EN55024. EN1000-6-1 Class A light industry standard |
|||||
|
OTHERS |
MTBF |
≥370K hrs. MIL-HDBK-217F(25℃) |
||||
|
Dimension |
159*98*38mm(L*W*H) |
|||||
|
Packing |
0.45Kg:30PCS/14Kg/0.9CUFT |
|||||
