MODEL | S-500-12 | S-500-24 | S-500-36 | S-500-48 |
DC Voltage | 12V | 24V | 36V | 48V |
Rated Current | 40A | 20A | 13.8A | 10A |
Current range | 0~40A | 0~20A | 0~13.8A | 0~10A |
Rated power | 480W | 480W | 496.8W | 480W |
Ripple&noise | 150mVp-p | 150mVp-p | 200mVp-p | 200mVp-p |
Voltage ADJ. | 12~14V | 24~28V | 36~38V | 48~53V |
Efficiency | 82% | 85% | 85% | 85% |
Over load | 105%~150% in rated output power | |||
Protection type: Hiccup mode,recovers automatically after fault condition is removed | ||||
Over voltage | 15~16.5V | 29~33V | 40~45V | 58~65V |
Protection mode,tum off output voltage, restart to recover | ||||
