| Model | LRS-100-5 | LRS-100-12 | LRS-100-24 | LRS-100-48 |
| DC Voltage | 5V | 12V | 24V | 48V |
| Rated Current | 18A | 8.5A | 4.5A | 2.3A |
| Current range | 0~18A | 0~8.5A | 0~4.5A | 0~2.3A |
| Rated power | 90W | 102W | 108W | 110.4W |
| Ripple&noise | 100mVp-P | 120mVp-p | 150mVp-p | 200mVp-p |
| Voltage ADJ. | 4.5~5.5V | 10.2~13.8V | 24~28V | 43.2~52.8V |
| Efficiency | 86% | 89% | 90% | 91.5% |
Over load |
115%~150% in rated output power | |||
| Protection type: Hiccup mode, recovers automatically after fault condition is removed | ||||
Over voltage |
5.75~6.9V | 13.8~16.2V | 28.8~33.6V | 55.2~64.8V |
| Protection mode, tum off output voltage, restart to recover | ||||
